Weld penetration systems

Product Description

SOFTWARE FEATURES: - (1) Weld Penetration:

(a) Penetration depth & percentage (b) Leg

measurement

(c) Throat measurement (d) Thickness

measurement

(e) Can set tolerances for each parameters. (f)

Can feed sample information in Report. (g) Automatic pass/fail status identification

based on observed value and tolerances. (2) Calibration: This tool is used for calibrating

through calibration scale. (3) Dimensional Measurement:

(a) Line (b) Length (Linear, Horizontal, Vertical)

(c) Angle (two-line angle, three-line angle) (d)

Distance (two point)

(e) Radius (three point) (f) Diameter (three

point)

(4) Report:

(a) PDF & M.S. Excel

(b) Printout with Processed imaged and results.
